PCIe Retimer
RegliTM
When it comes to PCIe, every nanosecond counts. Kandou AI's fully compliant Regli PCIe retimer operates at ultra-low latency (under 13 nanoseconds).
Why Regli™
Exceptional Signal Integrity
RegliTM actively participates in link equalization to help maintain PCIe Gen5 link integrity for GPUs, XPUs, and NVMe SSDs
Security-minded
Our in-house security team keeps security at the helm of every decision, ensuring complete peace of mind
Rapid Response
Operating at sub-13 nanoseconds latency, RegliTM is one of the fastest PCle retimers in the world
System Designer's Dream
With class-leading bifurcation and on-chip diagnostics across the RegliTM product family, you get the fit and reliability that designers love.
Complete feature list
PCIe 5.0 support up to 32 GT/s, x16/x8/x4 bidirectional lanes
CXL 1.0 and CXL 2.0 support
Extended system reach
Improved signal integrity
Ultra-low latency
Simplified system design
Multiple control interface
- SMBus slave or I2C slave (BMC connection)
- EEPROM master
- SPI master (SPI flash)
- GPIO strapping pins for lane bifurcation configuration
- JTAG
Flexible clock mode
On-chip diagnostics
Power supply:
- Regular power mode- two supply rails, 1.8V and 0.9V. Reduced power mode- three supply rails, 1.8V, 1.2V/1.5V and 0.9V
Discover the Regli™ retimer family
Protocol-aware PCIe Gen 5 and CXL retimers delivering ultra-low latency and extended reach for demanding compute, AI, and storage applications.
KB9003
KB9002
KB9001
Powered by Copper MIMO
(Chord SignalingTM)
